Hot Rolled Coils

1.8–16.0mm hot rolled coils from 1580mm continuous rolling line. Carbon, structural, automotive, and pipe-grade steels.

Commercial Hot Rolled Coils

General-purpose structural and forming grades. Width 700–1,500mm. Coil ID 762mm, max OD 2,080mm.

CategoryRepresentative GradesThickness (mm)Standard
Carbon StructuralQ195, Q235A/B/C/D, Q275, SS330, SS400, A36, S235JR, S275JR1.8 – 16.0GB/T 3274, JIS G3101, ASTM A36, EN 10025
Low-Alloy StructuralQ355B/C/D, Q390B/C/D, Q420B/C, Q460C, S355J2, A572 Gr.50, SS490, St52-32.3 – 16.0GB/T 1591, EN 10025, ASTM A572
Pipe & TubeSPHT1-3, S275J0H, S355MH, X42-X70 (API 5L PSL2)2.3 – 16.0JIS G3132, EN 10219, API 5L
Boiler & VesselQ245R, Q345R, HP235-HP345, SG295-Cr2.0 – 16.0GB 713, GB 6653
Weathering SteelSPA-H, 09CuPCrNi-A, Q355GNH, Q450NQR12.3 – 16.0JIS G3125, GB/T 4171, TB/T 1979

Automotive Hot Rolled Coils

Structural, chassis, and wheel steels for automotive manufacturing. High surface quality and dimensional accuracy.

CategoryRepresentative GradesThickness (mm)Standard
Auto StructuralSAPH310, SAPH370, SAPH400, SAPH440, QStE380TM–QStE550TM1.8 – 16.0JIS G3113
Frame / Chassis510L, 610L, 700L, X510L, XG800L2.0 – 16.0GB/T 3273
Wheel Steel330CL, 380CL, 490CL, 590CL2.5 – 16.0YB/T 4151
Mechanical StructureS20C, S35C, S45C, S50C, 40Mn, 65Mn, 30CrMo, 50CrVA2.3 – 12.0JIS G4051, GB/T 711, GB/T 3077

Pickled & Oiled Coils

Hot rolled pickled coils with superior surface finish. For automotive exposed panels, stamping, and cold forming.

CategoryRepresentative GradesThickness (mm)Width (mm)
Low-CarbonSPHC-B, SPHC-S, SPHC-HY1.8 – 10.0700 – 1,500
Carbon StructuralQ235B-S2.0 – 10.0700 – 1,500
AutomotiveSAPH310–440, QStE380TM–550TM, 510L, 610L2.0 – 10.0700 – 1,500
Wheel Steel330CL, 380CL, 420CL, 490CL, 590CL2.0 – 10.0700 – 1,500

Electrical Steel Base (Cold Rolling Substrate)

Hot rolled substrate for non-oriented electrical steel production. Optimized chemistry for low core loss and high permeability.

Grade SeriesRepresentative GradesThickness (mm)Standard
Standard GradesXG1300WR, XG1000WR, XG800WR, XG700WR, XG600WR2.2 – 3.0Q/XGJ 116
High-GradeXG600WY, XG600WM, XG470WR, XG400WR, XG350WR, XG250WR2.2 – 3.0Q/XGJ 116
